| Model |
GE Series |
| Specification |
1U 19-inch rack-mountable, depth 420mm, supports rack mounting and wall mounting |
| CPU |
Supports 1x new 4th/5th Gen Intel Xeon Scalable Processor, Max Power 225W |
| Memory |
Up to 6x DDR5 4800 MT/s memory modules |
| Storage |
Front: Up to 4x 2.5" HDD/SSD |
| |
Internal: Up to 1x M.2 SSD hard drive |
| Storage Controller |
Onboard SATA controller, supports RAID 0/1/5/10 |
| |
Optional external SAS/RAID card, supports multiple RAID modes |
| Network |
Standard PCIe Ethernet: Supports external, speed up to PCIe4.0 X16 |
| |
Onboard Network Card: Integrated 2x10 RJ45 ports, optional X10 dual-port network card, supports 1588 PTP protocol |
| |
OCP Network Card: Optional 1x OCP 3.0 network card, up to PCIe4.0 X16 |
| I/O Expansion Slots |
Up to 2x expandable PCIe4.0 x16 slots, supports multi-PIN defined clock accelerators through optional PCIe riser card |
| |
Up to 2x HHL single-width GPUs or 1x FHFL 150W powered GPU |
| |
Motherboard supports 2x8 MCIO, can meet non-standard external card customization |
| Interface |
Front: 2x USB 3.0 ports, 1x VGA port, 1x UID indicator light and button, 2x RS422 interfaces, 1x IPMI interface |
| Fan |
5x hot-swappable N+1 redundant 4056 fans (dual rotor) |
| Power Supply |
Supports 2x 550W/800W (Platinum/Titanium/ClassB), DC/AC power supply, 1+1 redundancy |
| System Management |
Onboard BMC management module, supports IPMI/SOL/KVM Over IP/Virtual Media and other management features, supports NCSI function |
| Operating System |
Supports KOS/Windows/Red Hat/SUSE/Centos/Ubuntu and other mainstream operating systems |
| Dimensions |
W (Width) 448mm (H) 44.5mm (D) 420mm |
| Weight |
Full Load < 25kg, please refer to the technical white paper for details |
| Working Environment |
-5°C ~ 55°C, please refer to the technical white paper for details |
| |
Supports 9-level earthquake resistance |
| |
Optional front panel dust cover supported |
